Covers Class 150 and Class 300 metal ball valves that have either butt-welding or flanged ends and are for use in on-off service.

Product Details

Edition:

3rd

Published:

08/01/2002

ANSI:

ANSI Approved

Number of Pages:

20

File Size:

1 file , 280 KB

Product Code(s):

C60803R, C60803, C60803, C60803R, C60803, C60803R

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria

Click here to purchase
This standard specifies the requirements for metal ball valves suitable for petroleum, petrochemical and industrial applications that have:

• flanged ends in sizes NPS 1/2 through NPS 20 (DN15 through DN500);
• butt-welding ends in sizes NPS 1/2 through NPS 20 (DN15 through DN500);
• socket-welding ends in sizes NPS 1/4 through NPS 2 (DN8 through DN50);
• threaded ends in sizes NPS 1/4 through NPS 2 (DN8 through DN50).

Corresponding to the nominal pipe sizes in ASME B36.10M.

This standard applies to metal ball valves with pressure classes as follows:

• flanged ends in Classes 150, 300 and 600 (PN16, 25, 40 and 100);
• butt-welding ends in Classes 150, 300 and 600 (PN16, 25, 40 and 100);
• socket-welding ends in Classes 150, 300, 600 and 800 (PN16, 25, 40 and 100);
• threaded ends in Classes 150, 300, 600 and 800 (PN16, 25, 40 and 100).

This standard establishes requirements for bore sizes described as:

• full bore;
• single reduced bore;
• double reduced bore.

This standard applies to floating ball valve designs and trunnion ball valve designs. These figures are to be used only for the purpose of establishing standard nomenclature for valve components- other floating and trunnion designs also exist.

This standard establishes additional requirements for ball valves that are otherwise in full conformance to the requirements of ASME B16.34, Standard Class.

Product Details

Published:

12/01/2008

ANSI:

ANSI Approved

Number of Pages:

17

File Size:

1 file , 460 KB

Redline File Size:

2 files , 850 KB

Product Code(s):

C60804, C60804, C60804, C60804, C60804, C60804

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria

Click here to purchase
This standard specifies the requirements for metal ball valves suitable for petroleum, petrochemical, and industrial applications that have:

• flanged ends in sizes DN 15 through DN 600 (NPS 1/2 through NPS 24);
• butt-welding ends in sizes DN 15 through DN 600 (NPS 1/2 through NPS 24);
• socket-welding ends in sizes DN 8 through DN 50 (NPS 1/4 through NPS 2);
• threaded ends in sizes DN 8 through DN 50 (NPS 1/4 through NPS 2).

Corresponding to the nominal pipe sizes in ASME B36.10M.

This standard applies to metal ball valves with pressure classes as follows:

• flanged ends in Classes 150, 300, and 600;
• butt-welding ends in Classes 150, 300, and 600;
• socket-welding ends in Classes 150, 300, 600, and 800;
• threaded ends in Classes 150, 300, 600, and 800.

This standard establishes requirements for bore sizes described as:

• full bore;
• single reduced bore;
• double reduced bore.

This standard applies to floating (seat-supported) ball (Figure B.1) and trunnion ball valve designs (Figure B.2). These figures are to be used only for the purpose of establishing standard nomenclature for valve components – other floating and trunnion designs also exist.This standard establishes additional requirements for ball valves that are otherwise in full conformance to the requirements of ASME B16.34, Standard Class.

Product Details

Edition:

5th

Published:

11/01/2012

Number of Pages:

28

File Size:

1 file , 480 KB

Redline File Size:

2 files , 5 MB

Product Code(s):

C60805, C60805, C60805, C60805, C60805, C60805, C60805, C60805, C60805

Note:

This product is unavailable in Cuba, Iran, North Korea, Syria
